H40M00P390S

    Model No. H40M00390S H40M00390SF
    OC Model  AUO T390HVN05.0 AUO P390HVN01.0
    Aspect Ratio A+:A(033:335=8:2) A+:A(033:335=8:2)
    Panel Type  Ordinary display (without border) Ordinary display (without border)
    Display Type LED Display, Full View Display LED Display, Full View Display
    Panel   LED Display Type AUO AUO
    Curvature Curved Screen Curved Screen
    Screen Size 39” 39”
    Native Resolution 1920x1080 1920x1080
    Backlight LED Backlight LED Backlight
    Brightness(Max) 260cd/m2 260cd/m2
    Brightness 180+/-20cd/m2 180+/-20cd/m2
     Default Color Temperature warm warm
    Contrast Ratio Static Contrast Ratio: 1000 : 1 Static Contrast Ratio: 1000 : 1
    Dynamic Contrast Ratio: Million level Dynamic Contrast Ratio: Million level
     Number of Colors 16.7M 16.7M
     Viewing Angle 178°(H)/178°(V) 178°(H)/178°(V)
     Response time 8ms 6ms
     Refresh Frequency 60Hz 144Hz
     Pixel Pitch 0.44475 0.44475
      Interface Type VGA+HDMI,No Audio DP+DVI+HDMI, No Audio
    Power Supply  Input Voltage 100-240V AC,50-60Hz 100-240V AC,50-60Hz
    Type Internal power supply External power supply
    Power Consumption 55W(Standby power consumption0.5W)  55W(Standby power consumption0.5W)
    Structure Color Black Black
    Monitor size 881.3*64.7*514.9mm(without stand) 881.3*64.7*514.9mm(without stand)
    881.3*207.7*572.8mm(with stand) 881.3*207.7*572.8mm(with stand)
    975*600*190mm(With Packaging) 975*600*190mm(With Packaging)
     Weight  NW: About 9.2kg NW: About 9.2kg
     GW: About 11kg GW: About 11kg
     Wall Mounted Function  NA NA
     Base Function  Support Tilt  Support Tilt
     OSD Control  Control Mode  Button Button
     Menu Language English,Simplified Chinese English,Simplified Chinese
     Circumstance  Storage Temperature -20ºC~60ºC -20ºC~60ºC
     Working Temperature 0ºC~50ºC 0ºC~50ºC
     Working Humidity 10~90%RH 10~90%RH
     Energy Level 2015 III 2015 III
     Altitude 2000m 2000m
     Accessories List  Accessories HDMI Cable*1; Adapter*1 Instruction Manual+ Repair, replacement, return certificate +Qualified Certificate*1Charge base*1 DP Cable*1;Adapter*1 Instruction Manual+ Repair, replacement, return certificate +Qualified Certificate*1Charge base*1
